MS Lithium Rechargeable Battery
"MS621T" and "MS920T" have improved both higher and
lower temperature characteristics while leaving features of
the conventional MS rechargeable batteries.
They offers wider temperature range from -40°C to +85°C.
|
SPECIFICATIONS New !
|
Type
|
Nominal Voltage
(V) |
Nominal
Capacity
(mAh)*1 |
Internal
Impedance
(Ω)*2 |
OperatingTemperature Range |
| MS920T |
3 |
6.5 |
60 |
-40°C to +85°C |
| MS621T |
3 |
3.0 |
80 |
-40°C to +85°C |
|
| Type |
Nominal
Voltage
(V) |
Charg Voltage
(Standard
Charge Voltage)*6
(V) |
Nominal
Capacity
(mAh)*1
|
Internal
Impedance
(Ω)*2 |
Standard
Charge/
Discharge
Current
(mA) |
Maximum
Discharge
Current
(Continuosu)
(mA)*3 |
| MS414GE |
3 |
2.8 to 3.3 (3.1) |
2.0 |
100 |
0.010 |
0.05
|
| MS412FE |
3 |
2.8 to 3.3 (3.1) |
1.0 |
100 |
0.010 |
0.10 |
| MS518SE |
3 |
2.8 to 3.3 (3.1) |
3.4 |
60 |
0.010 |
0.15 |
| MS614SE |
3 |
2.8 to 3.3 (3.1) |
3.4 |
80 |
0.015 |
0.25 |
| MS621FE |
3 |
2.8 to 3.3 (3.1) |
5.5 |
80 |
0.015 |
0.25 |
| MS920SE |
3 |
2.8 to 3.3 (3.1) |
11.0 |
30 |
0.050 |
0.80 |
|
|
|
|
CPH Capacitor
CPH3225A is thinnest and smallest chip-type electric double
layer capacitor.
The unique ceramic packaging with superior air-tightness is
used. As the result, it offers leakage resistance and humidity
resistance. Also, by optimizing its materials, a 1 minute rapid
charge stores approximately 85% of full capacity.
lts heat-resistant design allows for Pb-free reflowable SMT
board attachment.
|
| SPECIFICATIONS |
|
| Type |
Maximum Use
Voltage (V) |
Nominal Capacity
(Voltage Range)
Capacitance |
Internal Impedance*
(Ω) |
| CPH3225A |
3.3 |
4.6uAh (3.3V-1.8V)
0.011F |
160 |
* Value measured using AC (Alternating Current) method at the discharged state.
|
|
 |
CPX Capacitors
- CPX Capacitors are chip-type Electric Double Layer Capacitor (DELC) that offer lower internal impedance and reducing the amount of leak current.
- CPX Capacitors allow discharge current up to several hundreds of mAs and super rapid charging by weak electromotive force.
|
| SPECIFICATIONS |
|
|
| Par number |
Maximum Use
Voltage
(V) |
Capacitance
(mF) |
Internal Impedance (ESR)
(Ω) |
Size (L×W×H)
(mm) |
CPX10080C104F
(Under Development) |
2.5 |
100 |
0.5 |
10.0×8.0×1.9 |
CPX10080C104F
(Under Development) |
3.3 |
100 |
1.5 |
10.0×8.0×1.9 |
CPX10080C402F
(Under Development) |
2.5 |
4 |
0.5 |
10.0×8.0×1.9 |
| CPX3225A752D |
2.6 |
7.5 |
25 |
3.2×2.5×0.9 |
|
|
|
|
XH Capacitors
The XH series capacitor has a better discharge characteristic
above 3V. It is an environmentally friendly product that
is reflow mounted by Pb-free soldering. It features high
capactity, and long-term reliability, as well as a wide operating
voltage range. It is thus suitable for backup power supply
of clock and memory functions on mobile and infomation
devices.
|
| SPECIFICATIONS |
|
|
| Type |
Electrical Specifications (Normal Temperature) *1 |
Maximum Use
Voltage (V) |
Capacitance (F) |
Internal Impedance*2 |
| XH311HG |
3.3 |
0.02 |
300 |
| XH311HU |
3.3 |
0.035 |
150 |
| XH414HG |
3.3 |
0.08 |
100 |
*1. Normal temperature: 23°C ± 3°C. Electrical characterisitics and aging
degradation of the products depend on temperature.
*2. Value measured using AC (Alternating Current ) method at the discharged state.
|
|
 |
Silver Oxide Battery
SEIZAIKEN. Silver Oxide Batteries by Seiko
lnstruments lnc., has grown with the history of
quartz watches. Silver Oxide Batteries have high
density of energy per volume and are able to supply
stable voltage for a long time. SEIZAIKEN Batteries
are suitable to power BLE(Bluetooth Low Engrgy).
wearable devices, and information devices.
|
| SPECIFICATIONS |
|
|
| Type |
Nominal
Voltage
(V) |
Nominal Capacity
(mAh) |
Discharge Level |
| SR**SW |
1.55 |
5.5 to 160 |
Low current |
| SR**W |
1.55 |
28 to 160 |
High current |
|
|
