參考規格
|
|
 UV Cut 370 nm
| Standard Spectral Transmittance: A.O.I=0° |
| Wave Length (nm) |
Transmission (%) |
| 370 +/- 10 nm |
T 50% |
|
Spectrum
 |
|
|
UV Cut 410 nm
| Standard Spectral Transmittance: A.O.I=0° |
| Wave Length (nm) |
Transmission (%) |
| 300-395 nm |
Tavg < 1% |
| 410 +/- 5 nm |
T 50% |
| 425-680 nm |
Tavg > 97% |
|
|
|
|
UV Cut 420 nm
| Standard Spectral Transmittance: A.O.I=0° |
| Wave Length (nm) |
Transmission (%) |
| 300-405 nm |
Tavg < 1% |
| 420 +/- 5 nm |
T 50% |
| 445-680 nm |
Tavg > 92% |
|
Spectrum
 |
|
|
UV Cut 425 nm
| Standard Spectral Transmittance: A.O.I=0° |
| Wave Length (nm) |
Transmission (%) |
| 300-395 nm |
Tavg < 1% |
| 425 +/- 5 nm |
T 50% |
| 445-680 nm |
Tavg > 97% |
|
Spectrum
|
|
|
UV Cut 437 nm
| Standard Spectral Transmittance: A.O.I=0° |
| Wave Length (nm) |
Transmission (%) |
| 320-420 nm |
Tavg < 0.5% |
| 437 +/- 5 nm |
T 50% |
| 457-680 nm |
Tavg > 97.5% |
|
Spectrum
|
|
|
Application
|
| Projector: LCD/DLP/LCOS, Lighting, Optical Instruments, Scientific Optical Applications. |
|
Available Sizes & Cutting Tolerance
|
|
|
|
|
Durability
|
-
Temperature Aging+65℃,95%RH, 500Hours
-
Hight/Low Temp +85°C/-40°C,30min/30min 100cycle
-
Chemical/Res,20°C Ether/alcohol,24Hours
-
Mechanical Res,3M Tape # 600 50 Times
|
|
|
Standard Specification
|
|
|
|
|
Available Glass Material
(Thickness & Maximum Operation Temperature)
|
-
Soda Lime Glass(Asahi)≒150°C：
0.1mm,0.2mm,0.7mm,1.3mm,2.1mm,3.0mm…etc。
-
Tempered Glass(schott D263/B270)≒250°C：
0.1mm,0.21mm,0.3mm,0.4mm,0.55mm,0.7mm,1.1mm…etc。
- Borofloat R33 Glass≒450°C：
1.1mm,2.0mm,3.3mm,3.8mm…etc。
|
|
|
Customer Design
|
- Design and Fabrication upon customer's specifications
Please fill out the Standard Inquiry Form we will contact you ASAP .
|
|
